Class 1 Div 1 Div 2 Explosion Proof Flood Light 85-265VAC Flame Proof Lights

Brand Name : CROWN EXTRA

Model Number : BAT51

Certification : ATEX,ROHS,CE,IECEX

Place of Origin : CHINA,JiangSu

MOQ : 1PC

Price : USD$37~USD$194/1PC

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100000 Piece/Pieces per Month

Delivery Time : 5-8 work days

Packaging Details : Cartoon Packing

Ex rate : Ex d e IIC T6 Gb DIP A21 TA

IP Degerr : IP65

Corros ion Resistant : WF2

Input Voltage : 220VAC 50/60Hz

Adapted lamp : 250W 400W,1000W(Metal Halide Lamp)

Mounting Styles : Pendant;Celling;Wall Bracket;Stanchion

Contact Now

Class 1 Div 1 Div 2 Explosion Proof Flood Light 85-265VAC Flame Proof Lights

Explosion proof flood light Overview
Quick Details
Color Temperature(CCT):
5700K
Input Voltage(V):
220VAC, 50/60 Hz
Lamp Luminous Efficiency(lm/w):
130
Warranty(Year):
1-Year
Color Rendering Index(Ra):
70
Support Dimmer:
NO
Lighting solutions service:
Lighting and circuitry design, DIALux evo layout, LitePro DLX layout, Agi32 layout, auto CAD layout, Onsite metering, Project Installation
Lifespan (hours):
20000
Working Time (hours):
50000
Product Weight(kg):
1.4
CRI (Ra>):
70
IP Rating:
IP65
Working Lifetime(Hour):
20000
Working Temperature(℃):
-20 - 400
Place of Origin:
Jiangsu, China
Brand Name:
Crown Extra
Light Source:
HID
Model:
BAT51
Voltage:
220V/50~60Hz
EX mark (Gas):
Ex d e IIC T6 Gb
Entrance rules:
G3/4"
Classification:
Group II, Catogory 2 GD; Class I, Division 1 and 2,Group A,B,C,D
Size:
525*305*180mm
Mounting style:
pendant;Ceiling,Wall Bracket, Stanchion
Adapted lamp:
250W, 400W, 1000W (Metal Halide Lamp)
Certification:
ATEX,RoHS,CE,CCC
Corrosion Resistant:
WF2

Supply Ability:100000 Piece/Pieces per Month

Class 1 Div 1 Div 2 Explosion Proof Flood Light 85-265VAC Flame Proof Lights



Explosion proof flood light Applications

1. A wide range of hazardous areas where ignitable vapors, dust, moisture and corrosive elements are present
2. Areas requiring frequent on-and-off of lights or power cycling- no warm up time required
3. Areas with high energy costs
4. Typical applications include: Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation



Features

1. Die casting shell made of cast aluminum alloy(cooper is less than 0.4%), surface is high voltage electrostatic spray paint after high speed shot blasting, good corrosion proof.
2. Stainless steel outer fasteners.
3. Tempered glass for transparent parts, high energy impact proof, anti glare design.
4. Easy installation and maintenance, reliable electrical performance.
5. With the hole for easy opening, and the patented structure( automatic suspended security structure), make lamp replacement fast, convenient and safe.



Class 1 Div 1 Div 2 Explosion Proof Flood Light 85-265VAC Flame Proof Lights



Electrical Data
Ex Marking
Ex d e IIC T6 Gb/ DIP A21 TA
Classification
Group II, Catogory 2 GD; Class I, Division 1 and 2,Group A,B,C,D;
IP Degree
IP65,IP66
Application
Zone 1, 2 & Zone 21, 22
Input Voltage
220VAC, 50/60 Hz
Wattage
250W, 400W, 1000W (Metal Halide Lamp)
Conduit Entries
G 3/4"
Mounting Styles
Pendant; Ceiling; Wall Bracket;Stanchion
Corrosion Resistant
WF2
