T5 T8 Flameproof Tube Light IP66 Ex Proof Fluorescent Lighting

Brand Name : CROWN EXTRA

Model Number : BYS-Explosion Proof Fluorescent Light

Certification : CE,IECEX,ROHS,ISO,ATEX,

Place of Origin : CHINA

MOQ : 1

Price : USD58PCS

Payment Terms : T/T, Western Union

Supply Ability : 100000PCS PER MONTH

Delivery Time : 5-7 WORK DAYS

Packaging Details : 142*25*17CM CTN

Name : T5/T8 Explosion Proof Fluorescent Light IP66 Ex-proof fluorescent lighting

Input voltage(v) : 220VAC, 50~60HZ

Ex Mark : Ex d e IIC T6 Gb/ DIP A21 TA

Ip rating : IP66

Item type : Explosion Proof Fluorescent Light

Emergency : Ballast can be added

MOQ : 1

Illuminance : 110~125Lm/W

Intended use : zone1 and 2, zone 21 and 22

Emitting color : 6000K

Tube Length : 0.6m/1.2m

Material : Explosion Proof ABS, Steel, LED Tube etc

Contact Now

T5/T8 Explosion Proof Fluorescent Light IP66 Ex-proof fluorescent lighting



Features of the product:
1. Scope of application: zone 1, zone2, zone21, zone22 hazardous area locations
IIA, IIB explosive gas atmosphere
2. The shell is made of ZLIO2 aluminum alloy die-casting, and the surface is high-voltage electrostatic spray
3. Tempered glass cover, with strong impact resistance
4. Both steel pipe and cable wiring are acceptable
5. Thread only: G3/4”

technical parameter:
Rated voltage: AC220V50/60HZ, rated power: 9Wx1, 9Wx2 (type l) 18Wx1x 18Wx2 (type ll)

Explosion-proof mark: ExdembllCT6Gb/ExtDA21 IP66T80°C, protection level: IP66, corrosion protection level: WF2

Optional function: human body induction.
Lead-in device: M25X1.5 lead-in specification, suitable for 9mm~12mm cables, terminal block: W4mm, reliable wire connection

Installation method: Ceiling type (X), wall type (b), boom type 1 (g1), boom type 2 (g2), guardrail type (h), flange type (f), hanging chain type (L ), curved rod type (w)



Main technical parameters
Rated power (W) 1×8/2×8 1×16/2×16
Rated voltage (V) 110V-250V
Luminous flux (LM) 880/1760 1760/3520
Average service life of light source (h) 80000
Protection class IP66
Ex Mark Ex edq II C T4 DIP A20 TA,T6
Lead in cable φ10mm-φ14mm
Introduction device G3/4"
Net weight (kg) Single tube 5.4kg, double tube 6.1kg
Parameters of T5 fluorescent lamp with emergency function are as follows:
Emergency starting time (S) 0.3
Charging time (h) 24
Emergency lighting time (min) 90
